specifications

Dimensions and weight

  • Overall length - 1750mm
  • Overall width - 1000mm
  • Overall height - 1180mm
  • Weight - +- 20kg
  • Seat width - 475mm
  • Seat depth - 420mm
  • Seat height - 480mm to 510mm
  • Backrest width - 420mm
  • Backrest height - 458mm
  • Front wheel - 300mm
  • Back wheel - 490mm (Recommended max weight 130kg)
  • Packed - 950mm Length x 550mm Width x 500mm Height
  • Frame : 3mm x 38mm aluminium tubing frame, 25mm aluminium tubing armrests, 3 x 32mm push handle
  • Fasteners : Stainless steel
  • Upholstery : Composition: 100% solution-dyed acrylic fibre
  • Finishing : Upholstery is soil and mould resistant, oil and water repellent with Teflon finish.
  • Breaking load : (UNI EN ISO 13934-1) warp: 1590.7 kg; weft: 864 kg
  • Wheels : Polyurethane Beach Balloon Wheels are specifically designed to navigate challenging terrains like soft sand, mud, gravel, grass and rock. They are also great on hard surface terrains like
    streets and sidewalks. Moving heavy, awkward loads is easy with our wheels, because WHEELEEZ® Wheels Go - Anywhere!
  • Front wheel : WHEELEEZ®30 cm Polyurethane Wheel; 25.4 mm Bearing
  • Rear wheels : WHEELEEZ® 49 cm Polyurethane Wheel; 25.4 mm Bearing

 ACCESSORIES

  • UMBRELLA - SPORT-BRELLA VERSA-BRELLA MIDNIGHT BLUE 1M X 1M
  • CUSTOM CARRY BAG - WITH CARRY HANDLES AND PADDED INNER LINING
  • HAND TROLLEY - FOR EASY TRANSPORT OF THE MOBIRIDER™ WHEN PACKED IN CARRY BAG
  • HEAD SUPPORT - UNIT FOR QUADRIPLEGIC USERS
  • 50MM PULL STRAP - USED FOR PULLING THE MOBIRIDER™
